Edge Exposure

These devices eliminate unwanted resist in the edges of LCD panels during the manufacturing process.

It is a device that performs exposure to remove unnecessary resist at the peripheral part in the manufacturing process of liquid crystal panel.
We have also launched "Titler with Edge Exposure" which has both peripheral exposure and Titler.

Features

  • Corresponds to the G11 substrate
  • It is possible to expose the central part of the substrate
  • Skip/Step exposure possible (as an option).
  • UV-LED can be used as light source for exposure (lengthens life of light source)
  • Proposal of 'Titler with Edge exposure' attached with Titler function

Application

Display field TFT・CF Substrate

Examples

Specifications

Allowable substrate size 300 × 400mm - 2940 x 3370mm
Glass substrate thickness 0.4-1.1mm
Takt time 45sec (G6)
Plate-edge exposure area -70mm
Light source UV-lamp or UV-LED
